VERTICAL HIGH-SPEED ROUND WIRE ENAMELING MACHINE SERIES
The MD series vertical high-speed round wire enameling machine is designed with the concept of "energy conservation, environmental protection，and high-precision control"，it features a national invention-patented high-efficiency hot air circulation system，adopts triple catalysist echnology，and is equipped with a full-computer intelligent automatic control system，enabling its products to achieve world-class quality.
MDLI4-4/18A
MDLI4-4/18B、C、D
Technical Parameters
MDLI4-4/18A
Wire Range
Φ0.80 -Φ2.00mm
Maximum Wire In OfInline Drawing
Φ2.60mm
Maximum Drawing Passes
7 ,Elongation( No.1-6：1.26，No.7：1.22)
Maximum Mechanical Speed
MAX200m/min
Wind-Up Bobbin
PT25-PT270
Retracting Mode
Auto reel alternation
Production and Power Consumption Sheet
WIRE RANGE
（mm） |
DIAMETER VELOCITY
（PEI） |
WIRE SPEED
（m/min） |
PRODUCTIVITY
（kg/24h） |
POWER CONSUMPTION
（kwh/kg） |
| 1.00 |
150 |
150 |
6000 |
0.75 |
| 1.50 |
130 |
87 |
8000 |
0.65 |
| 2.00 |
100 |
50 |
8000 |
0.65 |
Technical Parameters
MDLI4-4/18B、C、D
Wire Range
Φ1.50 - Φ3.00mm Φ2.00 - Φ4.00mm Φ2.50 - Φ5.00mm
Maximum Wire In OfInline Drawing
Φ4.00mm、Φ6.00mm
Maximum Drawing Passes
7 ,Elongation( No.1-6：1.26，No.7：1.22)
Coating Passes
18 , 16passes （die coating）
Maximum Mechanical Speed
MAX100m/min
Wind-Up Bobbin
PT25-PT270
Retracting Mode
Auto reel alternation
Production and Power Consumption Sheet
WIRE RANGE
（mm） |
DIAMETER VELOCITY
（PEI） |
WIRE SPEED
（m/min） |
PRODUCTIVITY
（kg/24h） |
POWER CONSUMPTION
（kwh/kg） |
| 1.50 |
130 |
87 |
8000 |
0.65 |
| 2.00 |
100 |
50 |
8000 |
0.65 |
| 3.00 |
80 |
27 |
9900 |
0.50 |
| 4.00 |
60 |
15 |
9900 |
0.55 |
| 5.00 |
55 |
11 |
10000 |
0.55 |
